STEUERBOX
Prolan's own-developed and manufactured device offers a solution to German energy suppliers
for tariff and power control and for regeneration of renewable power plants.
Webpage: steuerbox.eu
The device is connected to the new smart measuring system in Germany, called "Intelligent Messsysteme", one of its system elements.
• The role of electricity distribution: the establishment of network balance by influencing decentralized energy producers and consumers.
• Key features: interoperability, communication security by cryptographic protocols, 4 potential-free relay outputs
Detailed technical requirements for the device are provided by the VDE / FNN organization's requirements specification (https://www.vde.com/de/fnn).
We are continuously developing products in cooperation with German energy utility companies and manufacturers to fulfill the requirements of key users. Additionally, taking into account the specific needs will allow the product to adapt quickly and be interoperable with each element of the smart system.
Dimensions | 71.5 x 90 x 62 mm |
Mounting method | DIN rail or 3-point mounting |
Protocols | TLS 1.2 encryption; IPv4 and IPv6 network layer; IEC 61850 standard based communication |
Power supply | 230 VAC -15 % +15% |
Power consumption | max. 2,1 Watt (max. 0,01 A) |
Number of relays | 4 x 2A |
Peripherals | 2 x 100MBit/s ETHERNET |
Operating temperature | –25 °C .. 55 °C |
Protection class | IP30 |
